Insert for Wood Fireplace F.lli Lerda L-70 Plus Vulcano 14 Kw

Insert for Wood Fireplace F.lli Lerda L-70 Plus Vulcano 14 Kw

FLL70PLVU
Disponibile
2,536.25
1,445.70 Save 1,090.55
Tax included
Quantity

Order it before 19:00 of tomorrow and receive it 08-01-2025 with BRT - Express

  • Secure Payments and Easy Returns Secure Payments and Easy Returns
Description

The L-70 Plus Vulcano F.lli Lerda ventilated wood-burning fireplace insert, entirely made of steel, is designed for ducting in two rooms.



This insert is super robust: the Plus Vulcano line includes: the 6 mm combustion chamber; 8 mm baffle, grille and frame; double combustion already inserted and an innovative technology that allows for optimal combustion across the entire base of the hearth. Furthermore, it integrates a very large ash drawer with a closure on the upper part to easily empty the drawer.



If you have a fireplace that you use little or that you want to redevelop, this product is the one for you.



The wood-burning insert is very simple to assemble: the fan is plugged into the back of the fireplace and simply needs to be connected to a 220V power supply. Please remember that the fireplace is supplied with a fan, but the electrical connection must be made on site.



F.lli Lerda control unit with temperature kit code FLCENTR separately , which satisfies these requests. Otherwise, for manual on/off use and adjustment of the fan in one of the five speeds, simply purchase the F.lli Lerda Touch control unit code FLELX AIR .



For ducting we recommend using flexible aluminum or steel pipes and covering them with mineral wool, so as to avoid heat loss during the journey. The manufacturer guarantees good performance for ducts of up to 5 meters in length and made without elbow bends. The connection of the canalization pipes in the appropriate seats must be connected using connection sockets, code FLRaccordiCan .



F.lli Lerda wood-burning fireplace inserts are the best way to heat your rooms with maximum energy efficiency: the wood-burning fireplace becomes an excellent alternative or integration to traditional heating.

Ventilated wood-burning fireplace insert, black colour, in thick S235JR steel, with nominal thermal power of 14kw and 70% efficiency with approved autonomy of 8 hours. Complies with European standard EN 13229.



ceramic glass for high temperatures and a very large ash drawer with closing on the upper part.



Dimensions 70x59x50 cm with fan; internal dimensions of the hearth 42x59 cm; useful depth 33 cm. Model L-70, Plus Vulcano line, characterized by 6 mm combustion chamber, deflector, grille and 8 mm frame, F.lli Lerda brand.



Technical features:



  • 8mm deflector and frame grille
  • Combustion chamber 6 mm
  • Entirely made of high thickness S235JR steel
  • Nominal thermal power: 14 Kw
  • Yield: 70%
  • Carbon monoxide release rate in fumes: 0.23%
  • Average flue gas outlet temperature: 260 °C.
  • Continuous fire hearth
  • Approved autonomy: 8 hours
  • Product approved to European standard EN 13229
  • Dimensions (W x H x D): mm (700 x 590 x 500)
  • Internal dimensions of the hearth (H x W): mm (420 x 590)
  • Useful depth: 330mm
  • Firebox view (W x H): mm (500 x 300)
  • Ceramic glass for high temperatures 800°C
  • Ø smoke outlet 194 mm
  • Combustion air adjustment on the front
  • Removable ash drawer
  • Forced ventilation
  • Tangential fan with a flow rate of 200 cubic meters per hour
  • 2 ductable outlets Ø 100 mm
  • Warranty: 2 years

Attachments
Download
Scheda Tecnica

Download (2.04M)
